Ø10x10 mm Female Threaded Pot Magnet – M5x5, N35 Grade Cylindrical Neodymium Magnet

The Ø10x10 mm M5x5 N35 female threaded pot magnet is a compact, high-strength neodymium magnet designed for secure mounting in industrial and technical applications. Featuring an M5 x 5 mm internal thread, it allows for fast and stable attachment using standard screws or bolts.

Its N35 grade neodymium core offers excellent holding power. The magnet is embedded in a steel pot, which concentrates the magnetic force on the contact surface, significantly enhancing performance. The nickel coating provides resistance against corrosion and wear, ensuring long-lasting durability.

Technical Specifications:

• Outer Diameter: Ø10 mm

• Height: 10 mm

• Thread Size: M5 x 5 mm (female)

• Shape: Cylindrical pot magnet

• Core Material: Neodymium (NdFeB)

• Casing: Steel

• Grade: N35 – Strong magnetic pull

• Coating: Nickel – Corrosion-resistant finish

• Magnetization Direction: Axial (through thickness)

• Max Operating Temperature: 80°C

Application Areas:

• Mounting systems requiring threaded attachment

• Part fixing in industrial assemblies

• Sensor and electronic component mounting

• Fixtures, holders, mechanical positioning units

• DIY and hobby magnetic setups
