Ø16x5 mm N35 Male Threaded Neodymium Pot Magnet – M6x10 Stud, Compact High-Holding Magnet

The Ø16x5 mm M6x10 N35 male threaded neodymium pot magnet is a compact, high-strength magnetic solution designed for secure mounting via its M6 x 10 mm male stud. It allows for easy installation onto metallic parts, brackets, or machine components where strong and reliable magnetic holding is required.

Built with a N35 grade neodymium core and a durable steel pot casing, this magnet concentrates its magnetic field on the contact surface, significantly enhancing pull force. The nickel coating ensures excellent resistance against corrosion and wear, making it suitable for both industrial and mechanical use.

Its small size and strong holding capability make it ideal for automation systems, industrial equipment, fixture assemblies, and sensor mounting.

Technical Specifications:

• Outer Diameter: Ø16 mm

• Height: 5 mm

• Thread Type: M6 x 10 mm male stud

• Magnet Grade: N35 – Strong magnetic force

• Core Material: Neodymium (NdFeB)

• Casing: Steel pot

• Coating: Nickel – Corrosion-resistant

• Magnetization Direction: Axial (through thickness)

• Max Operating Temperature: 80°C

Application Areas:

• Mechanically mounted magnetic systems

• Machine and equipment part fixation

• Industrial fixtures and holders

• Sensor and automation equipment mounting

• Compact magnetic attachment in tight spaces
