Ø60x65 mm Super Strong Pot Magnet with Female Connection - 100 kg Holding Power
Ø60x65 mm Super Strong Pot Magnet with Female Connection - 100 kg Holding Power
0.00 TL
With installments starting from 0.00 TL!
| Stock | : | Sadece Teklif |
| Model | : | MGK-DS11 |
| Category | : | Neodyum Pot Mıknatıslar |
Ø60x65 mm Very Strong Pot Magnet
This 60 mm diameter lifting pot magnet is characterized by its high attraction and corrosion resistance. The pot magnet with female connection can be produced in desired sizes and powers. You can contact us for your wholesale magnet needs.
Neodymium strong pot magnet models have a very high attraction power unlike other magnets. For this reason, it is preferred by many companies and companies. Pot magnet types are coated with different materials depending on the area to be used. In this way, the durability level increases. On our site, you can find neodymium magnet types in cube, block, disk or cylindrical sizes. These different productions make the product ready for the area where it will be used. Product coatings can be:
- Copper
- Nickel
- Gold
- Zinc
- Tin
- Silver
Please contact us for the type of coating suitable for your needs.
The coating of the pot magnets we manufacture does not tarnish and maintains its durability for a long time.
Types of Strong Pot Magnets with Neodymium Female Connection We Produce
The list below includes our catalog sizes. Please contact us for your magnet orders in different sizes. You can also order wholesale magnets and benefit from discounts.
| Stock No | D | H | MXL | Watt | Weight | ||
| mm | mm | mm | Kg | N | Lbs | g | |
| MGK-DS1 | 6 | 20 | M3x5 | 0.6 | 6 | 1.3 | 4 |
| MGK-DS2 | 8 | 20 | M3x5 | 1.2 | 12 | 2.6 | 7.5 |
| MGK-DS3 | 10 | 20 | M4x7 | 2.4 | 24 | 5.3 | 11 |
| MGK-DS4 | 13 | 20 | M4x7 | 6 | 60 | 13 | 20 |
| MGK-DS5 | 16 | 20 | M4x7 | 9 | 90 | 20 | 30 |
| MGK-DS6 | 20 | 25 | M6x9 | 13 | 135 | 30 | 58 |
| MGK-DS7 | 25 | 35 | M6x9 | 19 | 190 | 42 | 131 |
| MGK-DS8 | 32 | 40 | M8x12 | 25 | 340 | 76 | 243 |
| MGK-DS9 | 40 | 50 | M8x12 | 40 | 700 | 157 | 480 |
| MGK-DS10 | 48 | 60 | M10x12 | 60 | 1000 | 225 | 900 |
| MGK-DS11 | 60 | 65 | M12x14 | 100 | 1700 | 382 | 1560 |
Pot Magnets by Quality and Grades
Sintered NdFeB magnets are powerful permanent magnets made from an alloy of neodymium, iron and boron. These magnets are known as the strongest magnets available. However, they have a low maximum temperature resistance. This can cause neodymium pot magnets to oxidize quickly. Therefore, you should accurately determine the temperature at which the magnet you want to buy will be used and choose the magnet accordingly.
The table below will help you in your selection of pot magnets in deep and long sizes.
In the table below you can see the grades, qualities and maximum temperature resistances of the magnets. You can order N35, N42 and N52 pot magnet grades.
| Degree | Quality | Br (KG) Min-Max | HcB (KOe) | Hci (KOe) | Bhmax (MGOe) Min-Max | Tmax |
| N | N35 | 11.8-12.2 | ≥10.9 | ≥12.0 | 33-36 | 80C / 176F |
| N38 | 12.2-12.6 | ≥11.3 | ≥12.0 | 36-39 | 80C / 176F | |
| N40 | 12.6-12.9 | ≥11.4 | ≥12.0 | 38-41 | 80C / 176F | |
| N42 | 12.9-13.3 | ≥11.5 | ≥12.0 | 40-43 | 80C / 176F | |
| N45 | 13.3-13.7 | ≥11.0 | ≥12.0 | 43-46 | 80C / 176F | |
| N48 | 13.7-14.1 | ≥10.5 | ≥11.0 | 45-49 | 80C / 176F | |
| N50 | 14.0-14.5 | ≥10.5 | ≥11.0 | 47-51 | 80C / 176F | |
| N52 | 14.3-14.8 | ≥10.5 | ≥11.0 | 49-53 | 80C / 176F | |
| N55 | 14.7-15.1 | ≥10.5 | ≥11.0 | 53-56 | 80C / 176F | |
| M | 35M | 11.8-12.2 | ≥10.9 | ≥14.0 | 34-36 | 100C / 212F |
| 38M | 12.2-12.6 | ≥11.3 | ≥14.0 | 36-39 |
